APC SMART-UPS RMXL3U
   Our Price: $719.95

REFURBISHED APC SMART UPS 2200RMXL3U

All refurbished UPS's come fully tested with a 90 day replacement performance guaranteed warranty.
All of our batteries come brand new and factory fresh, with a 2 year warranty. Does not include cables, software or any accessories.

BRAND NEW BATTERIES WITH 2 YEAR WARRANTY


Model: SU2200RMXL3U

APC Smart-UPS XL 2200 VA RM 3U 120V

Part Number: SU2200RMXL3U

Output

Output Power Capacity 1750 Watts / 2200 VA

Max Configurable Power 1750 Watts / 2200 VA

Nominal Output Voltage 120V

Output Voltage Distortion Less than 5% at full load

Output Frequency (sync to mains) 47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal

Crest Factor up to 5 : 1

Waveform Type Sine wave

Output Connections

(6) NEMA 5-15R

(2) NEMA 5-20R

Input

Nominal Input Voltage 120V

Input Frequency 50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

NEMA L5-30P

Cord Length 2.44 meters

Input voltage range for main operations 92 - 147V

Input voltage adjustable range for mains operation 86 - 154V

Batteries & Runtime

Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time 3 hour(s)

Replacement Battery RBC27

RBC™ Quantity 1

Replacement battery cartridge note

External Battery pack is SU48R3XLBP only.

Communications & Management

Interface Port(s) DB-9 RS-232,SmartSlot

Available SmartSlot™ Interface Quantity 1

Control panel : LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators

Audible Alarm : Alarm when on battery : distinctive low battery alarm : configurable delays

Emergency Power Off (EPO) : Optional

Surge Protection and Filtering

Surge energy rating 880 Joules

Filtering : Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Data Line Protection --

Physical

Maximum Height 133.00 mm

Maximum Width 483.00 mm

Maximum Depth 660.00 mm

Rack Height 3U

Net Weight 56.36 KG

Shipping Weight 63.18 KG

Shipping Height 305.00 mm

Shipping Width 610.00 mm

Shipping Depth 813.00 mm

Color Black

Environmental

Operating Environment 0 - 40 °C

Operating Relative Humidity 0 - 95%

Operating Elevation 0-3000 meters

Storage Temperature -15 - 45 °C

Storage Relative Humidity 0 - 95%

Storage Elevation 0-15000 meters

Audible noise at 1 meter from surface of unit 53.00 dBA

Online Thermal Dissipation 375.00 BTU/hr

Conformance

Regulatory Approvals CSA,FCC Part 15 Class A,UL 1449,UL 1778

APC Smart-UPS XL 2200 VA RM 3U 120V
